SRL-W series PVC mixer
The unit is used in mixing various materials mixing, colouring, drying of different materials in the field of plastics, rubber, daily chemical industry and so on. It is an ideal choice for you to produceplastic plate, pipe,special-shapedmaterialand degradation plastic.
The unit is developed by importing and absorbing overseas advanced technology. Mixing adopts negative pressure mixing principle. The electric equipments and meters all adopt imported famous brand. By adopting PLC control, it features high automatic level, good mixing result. The vane is made of stainless steel pressure die cast, and has passed the test of dynamic and static equilibrium. Especially the vane of the cooling machine adopts the spiral agitation. That makes the whole room no dead angle, quickening the cooling speed and discharging cleanly. The mixing result has come up to intemational advanced level.
Model |
SRL-W500/1600 |
SRL-W800/2000 |
SRL-W800/2500 |
SRL-W800x2/4000 |
SRL-W1000/2500 |
Total cubage(L) |
500/1600 |
800/2000 |
800/2500 |
1600/4000 |
1000/2500 |
Effective cubbage(L) |
330/1000 |
560/1400 |
600/1500 |
1120/2700 |
700/1750 |
Mixed speed(r/min) |
430/860/70 |
330/660/55 |
330/660/60 |
350/700/65 |
350/700/50 |
Heating & cooling manner |
electric heating self-friction/water cooling |
||||
Mixed time(min/batch) |
8-12 |
8-12 |
8-12 |
8-12 |
8-12 |
Motor Power(KW) |
47/67/15 |
83/110/22 |
83/110/30 |
83/110x2/45 |
83/110/22 |
Discharge method |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
Pneumatic |
