PP PE PS sheet extrusion machine line
- Material: PP PE PS material
2. Sheet width: 2000mm, Thickness: 2-4mm, three layers: first layer is 0.2-0.6mm, second layer is 2-3mm,third layer is 0.2-0.4mm thickness - Voltage: 3 phase /380V/ 50 Hz (depend on request)
- Sheet production capacity:400-500kg/h(For PP material)
- Workshop Dimension: 35m(length)×5m(width)×5m(height)
- Temperature: ≤40℃
- Manpower: 2-3 people
- Water consumption: Max. 15m3/h(can be recycled)
- Air consumption: 5m3/h,air pressure:0.6-0.8Mpa
Category:
Share
Describe
- SJ130/35 Single screw extruder with vacuum exhaust system, screen changer and melting pump 1set
- Screw loader for SJ130/35 extruder
- SJ65/33 Single screw extruder with screen changer and dry hopper, vacuum loader 2sets
- T-Die mold and ABC type distributor 1set
- Three rollers calendar machine 1set
- Roller temperature controller for calendar rollers 1set
- Cooling Bracket with online edge trimming unit, waste edge winders, and haul off machine 1set
- Cutter 1set
- Belt conveyor and stacker 1set
- Electric control system 1set
